Function
Code
Name Setting Range Default Change
F6-07
Acceleration/Deceleration
mode
0: Linear acceleration/deceleration
1-2: S-curve acceleration/deceleration
0
★
F6-08
Time proportion of
S-curve start segment
0.0% to (100.0% - F6-09) 30.0%
★
F6-09
Time proportion of
S-curve end segment
0.0% to (100.0% - F6-08) 30.0%
★
F6-10 Stop mode 0: Decelerate to stop; 1: Coast to stop 0
☆
F6-11
DC injection braking start
frequency
0.00 Hz to max. frequency 0.00 Hz
☆
F6-12
DC injection braking delay
time
0.0s to 100.0s 0.0s
☆
F6-13 DC injection braking level 0% to 100% 50%
☆
F6-14
DC injection braking
active time
0.0s to 100.0s 0.0s
☆
F6-15 Braking use ratio 0% to 100% 100%
☆
F6-18
Catching a spinning motor
current limit
30% to 200%
Model
dependent
★
F6-21
Demagnetization time
(effective for SVC)
0.00s to 5.00s
Model
dependent
☆
F6-23 Overexcitation selection
0: Disabled
1: Enabled during deceleration
2: Enabled in the whole process
0
☆
F6-24
Overexcitation
suppression current level
0% to 150% 100%
☆
F6-25 Overexcitation gain 1.00 to 2.50 1.25
☆
Group F7: Keypad Operation and Display
F7-00 LED default display check 0 to 1 0
☆
F7-01
MF.K key function
selection
0: MF.K key disabled
1: Switchover from remote control (terminal or
communication) to keypad control
2: Switchover between forward rotation and reverse
rotation
3: Forward jog
4: Reverse jog
0
★
F7-02
STOP/RESET key
function
0: STOP/RESET key enabled only in keypad control
1: STOP/RESET key enabled in any operation mode
1
☆
F7-03
LED display running
parameters 1
0000 to FFFF
Bit00: Running frequency 1 (Hz)
Bit01: Set frequency (Hz)
Bit02: Bus voltage (V)
Bit03: Output voltage (V)
Bit04: Output current (A)
Bit05: Output power (kW)
Bit06: Output torque (%)
Bit07: DI state
Bit08: DO state
Bit09: AI1 voltage (V)
Bit10: AI2 voltage (V)
Bit11: AI3 voltage (V)
Bit12: Count value
Bit13: Length value
Bit14: Load speed display
Bit15: PID reference
1F
☆
