Appendix C
-
166
-
Function
Code
Name Setting Range Default Change
F9-08
Braking unit applied
voltage
650 to 800 V 760V
★
F9-09 Auto reset times 0 to 20 0
☆
F9-10
Selection of DO action
during auto reset
0: Not act
1: Act
0
☆
F9-11 Delay of auto reset 0.1s to 100.0s 1.0s
☆
F9-12
Input phase loss/pre-
charge relay protection
Units position: Input phase loss protection
Tens position: Pre-charge relay protection
0: Disabled
1: Enabled
11
☆
F9-13
Output phase loss
protection
Units position: Output phase loss protection
0: Disabled
1: Enabled
Tens position: Output phase loss protection before running
0: Disabled
1: Enabled
01
☆
F9-14 1st fault type
0: No fault
1: Reserved
2: Overcurrent during acceleration
3: Overcurrent during deceleration
4: Overcurrent at constant speed
5: Overvoltage during acceleration
6: Overvoltage during deceleration
7: Overvoltage at constant speed
8: Pre-charge resistor fault
9: Undervoltage
10: AC drive overload
11: Motor overload
12: Power input phase loss
13: Power output phase loss
14: IGBT overheat
15: External fault
16: Communication fault
17: Contactor fault
18: Current detection fault
19: Motor auto-tuning fault
20: Encoder/PG card fault
21: Parameter read and write fault
22: AC drive hardware fault
23: Motor short circuited to ground
24: Reserved
25: Reserved
26: Accumulative running time reached
27: User-dened fault 1
28: User-dened fault 2
29: Accumulative power-on time reached
30: Load lost
31: PID feedback lost during running
40: Fast current limit timeout
41: Motor switchover error during running
42: Too large speed deviation
43: Motor over-speed
45: Motor overheat
51: Initial position error
55: Slave error in master-slave control
-
●
F9-15 2nd fault type -
●
F9-16 3rd (latest) fault type -
●
F9-17
Frequency upon 3rd
(latest) fault
- -
●
