Appendix C
-
169
-
Function
Code
Name Setting Range Default Change
F9-63 Load lost protection
0: Disabled
1: Enabled
0
☆
F9-64 Load lost detection level 0.0% to 100.0% 10.0%
☆
F9-65 Load lost detection time 0.0 to 60.0s 1.0s
☆
F9-67 Overspeed detection level 0.0% to 50.0% (max. frequency) 20.0%
☆
F9-68 Overspeed detection time
0.0s: Not detected
0.1 to 60.0s
1.0s
☆
F9-69
Detection level of speed
error
0.0% to 50.0% (max. frequency) 20.0%
☆
F9-70
Detection time of speed
error
0.0s: Not detected
0.1 to 60.0s
5.0s
☆
F9-71
Power dip ride-through
gain Kp
0 to 100 40
☆
F9-72
Power dip ride-through
integral coefcient Ki
0 to 100 30
☆
F9-73
Deceleration time of
power dip ride-through
0 to 300.0s 20.0s
★
Group FA: PID Function
FA-00
PID reference setting
channel
0: Set by FA-01
1: AI1
2: AI2
3: AI3
4: Pulse reference (DI5)
5: Serial comms.
6: Multi-reference
0
☆
FA-01 PID digital setting 0.0% to 100.0% 50.0%
☆
FA-02
PID feedback setting
channel
0: AI1
1: AI2
2: AI3
3: AI1-AI2
4: Pulse reference (DI5)
5: Serial comms.
6: AI1 + AI2
7: Max. (|AI1|, |AI2|)
8: Min. (|AI1|, |AI2|)
0
☆
FA-03 PID operation direction
0: Forward
1: Reverse
0
☆
FA-04
PID reference and
feedback range
0 to 65535 1000
☆
FA-05 Proportional gain Kp1 0.0 to 1000.0 20.0
☆
FA-06 Integral time Ti1 0.01s to 10.00s 2.00s
☆
FA-07 Differential time Td1 0.000s to 10.000s 0.000s
☆
FA-08
PID output limit in reverse
direction
0.00 Hz to maximum frequency 0.00 Hz
★
FA-09 PID error limit 0.0% to 100.0% 0.0%
☆
FA-10 PID differential limit 0.00% to 100.00% 0.10%
☆
FA-11
PID reference change
time
0.00 to 650.00s 0.00s
☆
FA-12 PID feedback lter time 0.00 to 60.00s 0.00s
☆
FA-13 PID output lter time 0.00 to 60.00s 0.00s
☆
FA-14 Reserved - -
☆
FA-15 Proportional gain Kp2 0.0 to 1000.0 20.0
☆
FA-16 Integral time Ti2 0.01s to 10.00s 2.00s
☆
FA-17 Differential time Td2 0.000s to 10.000s 0.000s
☆
