Appendix C
-
170
-
Function
Code
Name Setting Range Default Change
FA-18
PID parameter switchover
condition
0: No switchover
1: Switchover via DI
2: Auto switchover based on PID error
3: Auto switchover based on running frequency
0
☆
FA-19
PID error 1 for auto
switchover
0.0% to FA-20 20.0%
☆
FA-20
PID error 2 for auto
switchover
FA-19 to 100.0% 80.0%
☆
FA-21 PID initial value 0.0% to 100.0% 0.0%
☆
FA-22
PID initial value active
time
0.00 to 650.00s 0.00s
☆
FA-23 Reserved - -
-
FA-24 Reserved - -
-
FA-25 PID integral property
Units position: Integral separation
0: Disabled
1: Enabled
Tens position: Whether to stop integral operation when the
PID output reaches the limit
0: Continue integral operation
1: Stop integral operation
00
☆
FA-26
Detection level of PID
feedback loss
0.0%: No detection
0.1% to 100.0%
0.0%
☆
FA-27
Detection time of PID
feedback loss
0.0s to 20.0s 0.0s
☆
FA-28
Selection of PID operation
at stop
0: Disabled
1: Enabled
0
☆
Group FB: Fixed Length and Count
FB-05 Set length 0 to 65535 m 1000m
☆
FB-06 Actual length 0 to 65535 m 0m
☆
FB-07 Number of pulses per meter 0.1 to 6553.5 100.0
☆
FB-08 Set count value 1 to 65535 1000
☆
FB-09 Designated count value 1 to 65535 1000
☆
Group FC: Multi-Reference and Simple PLC Function
FC-00 Reference 0 -100.0% to 100.0% 0.0%
☆
FC-01 Reference 1 -100.0% to 100.0% 0.0%
☆
FC-02 Reference 2 -100.0% to 100.0% 0.0%
☆
FC-03 Reference 3 -100.0% to 100.0% 0.0%
☆
FC-04 Reference 4 -100.0% to 100.0% 0.0%
☆
FC-05 Reference 5 -100.0% to 100.0% 0.0%
☆
FC-06 Reference 6 -100.0% to 100.0% 0.0%
☆
FC-07 Reference 7 -100.0% to 100.0% 0.0%
☆
FC-08 Reference 8 -100.0% to 100.0% 0.0%
☆
FC-09 Reference 9 -100.0% to 100.0% 0.0%
☆
FC-10 Reference 10 -100.0% to 100.0% 0.0%
☆
FC-11 Reference 11 -100.0% to 100.0% 0.0%
☆
FC-12 Reference 12 -100.0% to 100.0% 0.0%
☆
FC-13 Reference 13 -100.0% to 100.0% 0.0%
☆
FC-14 Reference 14 -100.0% to 100.0% 0.0%
☆
FC-15 Reference 15 -100.0% to 100.0% 0.0%
☆
FC-16 Simple PLC running mode
0: Stop after running one cycle
1: Keep nal values after running one cycle
2: Repeat after running one cycle
0
☆
