Appendix C
-
174
-
Function
Code
Name Setting Range Default Change
FE-27 User-dened parameter 27 F0-00 to FP-xx
A0-00 to Ax-xx
U0-00 to U0-xx
U3-00 to U3-xx
F0.00
☆
FE-28 User-dened parameter 28 F0.00
☆
FE-29 User-dened parameter 29 F0.00
☆
Group FP: Function Parameter Management
FP-00 User password 0 to 65535 0
☆
FP-01 Parameter initialization
0: No operation
01: Restore factory parameters except motor parameters
02: Clear records
04: Back up current user parameters
501: Restore user backup parameters
0
★
FP-02
Parameter display
property
Unit's digit: Group U is not displayed.
0: Not displayed
1: Displayed
Ten's digit: Group A is displayed.
0: Not displayed
1: Displayed
11
★
FP-03
Selection of individualized
parameter display
Units position: Selection of user-dened parameter display
0: Not displayed
1: Displayed
Tens position: Selection of user-modied parameter display
0: Not displayed
1: Displayed
00
☆
FP-04
Selection of parameter
modication
0: Disabled
1: Enabled
0
☆
Group A0: Torque Control and Limit
A0-00
Speed/Torque control
selection
0: Speed control
1: Torque control
0
★
A0-01
Torque reference source
in torque control
0: Set by A0-03
1: AI1
2: AI2
3: AI3
4: Pulse reference
5: Communication reference
6: Min. (AI1, AI2)
7: Max. (AI1, AI2)
Full scale of 1-7 corresponds to A0-03.
0
★
A0-03
Torque digital setting in
torque control
-200.0% to 200.0% 150.0%
☆
A0-05
Forward max. frequency
in torque control
0.00 Hz to max. frequency 50.00 Hz
☆
A0-06
Reverse max. frequency
in torque control
0.00 Hz to max. frequency 50.00 Hz
☆
A0-07
Acceleration time in
torque control
0.00s to 65000s 0.00s
☆
A0-08
Deceleration time in
torque control
0.00s to 65000s 0.00s
☆
Group A1: Virtual DI/DO
A1-00
VDI1 function selection
0 to 59 0
★
A1-01
VDI2 function selection
0 to 59 0
★
A1-02
VDI3 function selection
0 to 59 0
★
A1-03 VDI4 function selection 0 to 59 0
★
