Function
Code
Name Setting Range Default Change
A1-04 VDI5 function selection 0 to 59 0
★
A1-05
VDI active state setting
mode
Units position: VDI1
Tens position: VDI2
Hundreds position: VDI3
Thousands position: VDI4
Ten thousands position: VDI5
0: Decided by state of VDOx
1: Decided by A1-06
00000
★
A1-06
Selection of VDI active
state
0: Disabled
1: Enabled
Units position: VDI1
Tens position: VDI2
Hundreds position: VDI3
Thousands position: VDI4
Ten thousands position: VDI5
00000
★
A1-07
Function selection for AI1
used as DI
0 to 59 0
★
A1-08
Function selection for AI2
used as DI
0 to 59 0
★
A1-09
Function selection for AI3
used as DI
0 to 59 0
★
A1-10
Active state selection for
AI used as DI
0: High level active
1: Low level active
Units position: AI1
Tens position: AI2
Hundreds position: AI3
000
★
A1-11 VDO1 function selection
0: Short with physical DIx internally
1 to 41: See physical DO selection in group F5
0
☆
A1-12 VDO2 function selection
0: Short with physical DIx internally
1 to 41: See physical DO selection in group F5
0
☆
A1-13 VDO3 function selection
0: Short with physical DIx internally
1 to 41: See physical DO selection in group F5
0
☆
A1-14 VDO4 function selection
0: Short with physical DIx internally
1 to 41: See physical DO selection in group F5
0
☆
A1-15 VDO5 function selection
0: Short with physical DIx internally
1 to 41: See physical DO selection in group F5
0
☆
A1-16 VDO1 output delay 0.0s to 3600.0s 0.0s
☆
A1-17 VDO2 output delay 0.0s to 3600.0s 0.0s
☆
A1-18 VDO3 output delay 0.0s to 3600.0s 0.0s
☆
A1-19 VDO4 output delay 0.0s to 3600.0s 0.0s
☆
A1-20 VDO5 output delay 0.0s to 3600.0s 0.0s
☆
A1-21
VDO active mode
selection
0: Positive logic active
1: Negative logic active
Units position: VDO1
Tens position: VDO2
Hundreds position: VDO3
Thousands position: VDO4
Ten thousands position: VDO5
00000
☆
Group A2: Motor 2 Parameters
A2-00 Motor type selection
0: Common asynchronous motor
1: Variable frequency asynchronous motor
0
★
A2-01 Rated motor power 0.1 to 1000.0 kW
Model
dependent
★
A2-02 Rated motor voltage 1 to 2000 V
Model
dependent
★
