Inovance MD500

Appendix C
-
179
-
Function
Code
Name Setting Range Default Change
A6-29
Jump amplitude of AI3
input corresponding
setting
0.0% to 100.0% 0.5%
☆
Group A7: User Programmable Card
A7-00
User programmable
function selection
0: Disabled
1: Enabled
0
★
A7-01
Control board output
terminal control mode
selection
0: AC drive control
1: User programmable card control
Units position: FMR (FM used as digital output)
Tens position: Relay (T/A-T/B-TC)
Hundreds position: DO1
Thousands position: FMP (FM used as pulse control)
Ten thousands position: AO1
0
★
A7-02
Programmable card AIAO
function selection
0: AI3 (voltage input), AO2 (voltage output)
1: AI3 (voltage input), AO2 (current output)
2: AI3 (current input), AO2 (voltage output)
3: AI3 (current input), AO2 (current output)
4: AI3 (PTC input), AO2 (voltage output)
5: AI3 (PTC input), AO2 (current output)
6: AI3 (PT100 input), AO2 (voltage output)
7: AI3 (PT100 input), AO2 (current output)
0
★
A7-03
Selection PLC program
controlling the FMP output
0.0% to 100.0% 0.0%
☆
A7-04
Selection of PLC program
controlling the AO1
output
0.0% to 100.0% 0.0%
☆
A7-05
Selection of PLC program
controlling digital output
In decimal
Units position: FMR
Tens position: Relay 1
Hundreds position: DO
000
☆
A7-06
Setting frequency
reference via the user
programmable card
-100.00% to 100.00% 0.0%
☆
A7-07
Setting torque
reference via the user
programmable card
-200.0% to 200.0% 0.0%
☆
A7-08
Setting running
command via the user
programmable card
0: No command
1: Forward run
2: Reverse run
3: Forward jog
4: Reverse jog
5: Coast to stop
6: Decelerate to stop
7: Fault reset
0
☆
A7-09
Setting torque
reference via the user
programmable card
0: No fault
80 to 89: User-dened fault code
0
☆
Group A8: Point-point Communication
A8-00
Point-point
communication
0: Disabled
1: Enabled
0
☆
A8-01 Master or slave selection
0: Master
1: Slave
0
☆
