Inovance MD500

Appendix C
-
178
-
Function
Code
Name Setting Range Default Change
A5-05
Voltage over modulation
coefcient
100 to 110% 105%
★
A5-06 Undervoltage threshold 210 to 420V 350V
☆
A5-08 Low speed frequency 0.0 to 8.0 kHz 0.0
☆
A5-09 Overvoltage threshold 200.0V to 2500.0V
Model
dependent
★
A5-11
DC injection braking
threshold at low speed
0.00 to 5.00 Hz 0.30 Hz
☆
Group A6: AI Curve Setting
A6-00 AI curve 4 min. input -10.00V to A6-02 0.00V
☆
A6-01
Corresponding
percentage of AI curve 4
min. input
-100.0% to +100.0% 0.0%
☆
A6-02
AI curve 4 inexion 1
input
A6-00 to A6-04 3.00V
☆
A6-03
Corresponding
percentage of AI curve 4
inexion 1 input
-100.0% to +100.0% 30.0%
☆
A6-04
AI curve 4 inexion 2
input
A6-02 to A6-06 6.00V
☆
A6-05
Corresponding
percentage of AI curve 4
inexion 2 input
-100.0% to +100.0% 60.0%
☆
A6-06 AI curve 4 max. input A6-04 to +10.00V 10.00V
☆
A6-07
Corresponding
percentage of AI curve 4
max. input
-100.0% to +100.0% 100.0%
☆
A6-08 AI curve 5 min. input -10.00V to A6-10 -10.00V
☆
A6-09
Corresponding
percentage of AI curve 5
min. input
-100.0% to +100.0% -100.0%
☆
A6-10
AI curve 5 inexion 1
input
A6-08 to A6-12 -3.00V
☆
A6-11
Corresponding
percentage of AI curve 5
inexion 1 input
-100.0% to +100.0% -30.0%
☆
A6-12
AI curve 5 inexion 2
input
A6-10 to A6-14 3.00V
☆
A6-13
Corresponding
percentage of AI curve 5
inexion 2 input
-100.0% to +100.0% 30.0%
☆
A6-14 AI curve 5 max. input A6-12 to 10.00 V 10.00V
☆
A6-15
Corresponding
percentage of AI curve 5
max. input
-100.0% to +100.0% 100.0%
☆
A6-24
Jump point of AI1 input
corresponding setting
-100.0% to 100.0% 0.0%
☆
A6-25
Jump amplitude of AI1
input corresponding
setting
0.0% to 100.0% 0.5%
☆
A6-26
Jump point of AI2 input
corresponding setting
-100.0% to 100.0% 0.0%
☆
A6-27
Jump amplitude of AI2
input corresponding
setting
0.0% to 100.0% 0.5%
☆
A6-28
Jump point of AI3 input
corresponding setting
-100.0% to 100.0% 0.0%
☆
