Integra DRX-8.4 User Manual

128
Setup
6. Hardware 1. HDMI Change the settings for the HDMI functions. p149
2. Network Change the settings for the Network functions.
p151
3. Bluetooth Change the settings for the BLUETOOTH function.
p154
4. Power Management Change the settings for the power-save function.
p156
5. 12V Trigger A Change the settings for 12V TRIGGER OUT A jack.
p158
6. 12V Trigger B Change the settings for 12V TRIGGER OUT B jack.
p159
7. 12V Trigger C Change the settings for 12V TRIGGER OUT C jack.
p160
8. Works with SONOS Change the settings to connect with the Sonos Connect.
p161
7. Multi Zone 1. Zone 2 Change the settings for Zone 2.
p162
2. Zone 3 Change the settings for Zone 3.
p162
3. Remote Play Zone Change the settings for remote play.
p163
8. Miscellaneous 1. Tuner Change the settings for Tuner.
p164
2. Remote ID Change the remote controller ID.
p164
3. Firmware Update Change the settings for Firmware Update.
p164
4. Initial Setup Make the initial setup from the setup menu.
p165
5. Lock Lock the Setup menu so that the settings cannot be changed.
p165
6. Factory Reset All the settings are restored to factory defaults.
p165

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
