3. Board Test System
This kit includes an application called the Board Test System (BTS).
The BTS provides an easy-to-use interface to alter functional settings and observe the
results. You can use the BTS to test board components, modify functional parameters,
observe performance, and measure power usage. While using the BTS, you
reconfigure the FPGA several times with test designs specific to the functionality you
are testing.
Figure 5. Board Test System GUI
Several designs are provided to test the major board features. Each design provides
data for one or more tabs in the application. The Configure menu identifies the
appropriate design to download to the FPGA for each tab.
After successful FPGA configuration, the appropriate tab appears that allows you to
exercise the related board features. Highlights appear in the board picture around the
corresponding components.
