3.9. The Sleep Mode Tab
The Sleep Mode tab allows you to test the sleep mode aspect of the power
management controller.
Figure 14. The Sleep Mode Tab (Cropped View)
Table 11. Controls on the Sleep Mode Tab
Control Description
Running (or Sleeping) This control displays the mode status as sleeping or running. It is not
interactive.
Note This control displays board LED events related to the sleep mode.
Related Information
MAX 10 FPGA Configuration User Guide
Provides detailed explanations and options for MAX 10 device configuration.
