A.8.3. HDMI Video Output
The MAX 10 FPGA Development Kit supports one HDMI transmitter and one HDMI
receptacle.
The transmitter incorporates HDMI v1.4 features, and is capable of supporting an
input data rate up to 165 MHz (1080p at 60 Hz, UXGA at 60 Hz). The connection
between HDMI transmitter and MAX 10 is established in Bank 7, and the
communication can be done via I
2
C interface.
Table 30. HDMI Pin Assignments, Signal Names and Functions
Board
Reference
(U8)
Schematic Signal Name I/O Standard MAX 10
FPGA Pin
Number
Description
U8.62
HDMI_TX_D0
3.3 V A17 HDMI digital video data bus
U8.61
HDMI_TX_D1
3.3 V A18 HDMI digital video data bus
U8.60
HDMI_TX_D2
3.3 V A12 HDMI digital video data bus
U8.59
HDMI_TX_D3
3.3 V F16 HDMI digital video data bus
U8.58
HDMI_TX_D4
3.3 V A16 HDMI digital video data bus
U8.57
HDMI_TX_D5
3.3 V B12 HDMI digital video data bus
U8.56
HDMI_TX_D6
3.3 V F15 HDMI digital video data bus
U8.55
HDMI_TX_D7
3.3 V B11 HDMI digital video data bus
U8.54
HDMI_TX_D8
3.3 V A13 HDMI digital video data bus
U8.52
HDMI_TX_D9
3.3 V C15 HDMI digital video data bus
U8.50 HDMI_TX_D10 3.3 V C11 HDMI digital video data bus
U8.49
HDMI_TX_D11
3.3 V A11 HDMI digital video data bus
U8.48
HDMI_TX_D12
3.3 V A20 HDMI digital video data bus
U8.47
HDMI_TX_D13
3.3 V H13 HDMI digital video data bus
U8.46
HDMI_TX_D14
3.3 V E14 HDMI digital video data bus
U8.45
HDMI_TX_D15
3.3 V D12 HDMI digital video data bus
U8.44
HDMI_TX_D16
3.3 V C12 HDMI digital video data bus
U8.43
HDMI_TX_D17
3.3 V C19 HDMI digital video data bus
U8.42
HDMI_TX_D18
3.3 V C18 HDMI digital video data bus
U8.41
HDMI_TX_D19
3.3 V B19 HDMI digital video data bus
U8.40
HDMI_TX_D20
3.3 V B17 HDMI digital video data bus
U8.39
HDMI_TX_D21
3.3 V B16 HDMI digital video data bus
U8.38
HDMI_TX_D22
3.3 V C16 HDMI digital video data bus
U8.37
HDMI_TX_D23
3.3 V A15 HDMI digital video data bus
U8.53
HDMI_TX_CLK
3.3 V D6 Video clock
U8.63
HDMI_TX_DE
3.3 V C10 Video data enable
continued...
