Control Description
• prbs31: Selects pseudo-random 31-bit sequences.
• high_frequency: Divide by data pattern.
• low_frequency: Divide by data pattern.
Error Control • Detected errors: Displays the number of data errors detected in the
hardware.
• Inserted errors: Displays the number of errors inserted into the
transmit data stream.
• Bit error rate (BER): Displays the bit error rate of the interface
• Insert Error: Inserts a one-word error into the transmit data stream
each time you click the button.
• Clear: Resets the Detected errors and Inserted errors counters to
zeroes.
Test Control • Stop: Resets the test.
• Number of bits tested: Displays the number of bits tested since the
last reset.
