Control Description
• Detected errors—Displays the number of data errors detected in the
hardware.
• Inserted errors—Displays the number of errors inserted into the
transaction stream.
• Insert Error—Inserts a one-word error into the transaction stream
each time you click the button. Insert Error is only enabled during
transaction performance analysis.
• Clear—Resets the Detected errors and Inserted errors counters to
zeroes.
Address Range (Bytes) Determines the number of addresses to use in each iteration of reads and
writes.
