Board Reference
(U5 & U6)
Schematic Signal Name I/O Standard MAX 10
FPGA Pin
Number
Description
U5.P2 - U6.L2
DDR3_A5
1.5 V SSTL F19 Address bus
U5.R8 - U6.M8
DDR3_A6
1.5 V SSTL E21 Address bus
U5.R2 - U6.M2
DDR3_A7
1.5 V SSTL B20 Address bus
U5.T8 - U6.N8
DDR3_A8
1.5 V SSTL D22 Address bus
U5.R3 - U6.M3
DDR3_A9
1.5 V SSTL E22 Address bus
U5.L7 - U6.H7
DDR3_A10
1.5 V SSTL Y20 Address bus
U5.R7 - U6.M7
DDR3_A11
1.5 V SSTL E20 Address bus
U5.N7 - U6.K7
DDR3_A12
1.5 V SSTL J14 Address bus
U5.T3 - U6.N3
DDR3_A13
1.5 V SSTL C22 Address bus
U5.M2 - U6.J2
DDR3_BA0
1.5 V SSTL V22 Bank address bus
U5.N8 - U6.K8
DDR3_BA1
1.5 V SSTL N18 Bank address bus
U5.M3 - U6.J3
DDR3_BA2
1.5 V SSTL W22 Bank address bus
U5.K3 - U6.G3
DDR3_CASn
1.5 V SSTL U19 Row address bus
U5.K9 - U6.G9
DDR3_CKE
1.5 V SSTL W20 Clock enable
U5.J7 - U6.F7
DDR3_CLK_P
Differential 1.5 V
SSTL
D18 Differential output clock
U5.K7 - U6.G7
DDR3_CLK_N
Differential 1.5 V
SSTL
E18 Differential output clock
U5.L2 - U6.H2
DDR3_CSn
1.5 V SSTL Y22 Chip select
U5.E7
DDR3_DM0
1.5 V SSTL J15 Write mask byte lane 0
U5.D3
DDR3_DM1
1.5 V SSTL N19 Write mask byte lane 1
U6.B7
DDR3_DM2
1.5 V SSTL T18 Write mask byte lane 2
U5.E3
DDR3_DQ0
1.5 V SSTL J18 Data bus byte lane 0
U5.F7
DDR3_DQ1
1.5 V SSTL K20 Data bus byte lane 0
U5.F2
DDR3_DQ2
1.5 V SSTL H18 Data bus byte lane 0
U5.F8
DDR3_DQ3
1.5 V SSTL K18 Data bus byte lane 0
U5.H3
DDR3_DQ4
1.5 V SSTL H19 Data bus byte lane 0
U5.H8
DDR3_DQ5
1.5 V SSTL J20 Data bus byte lane 0
U5.G2
DDR3_DQ6
1.5 V SSTL H20 Data bus byte lane 0
U5.H7
DDR3_DQ7
1.5 V SSTL K19 Data bus byte lane 0
U5.D7
DDR3_DQ8
1.5 V SSTL L20 Data bus byte lane 1
U5.C3
DDR3_DQ9
1.5 V SSTL M18 Data bus byte lane 1
U5.C8
DDR3_DQ10
1.5 V SSTL M20 Data bus byte lane 1
U5.C2
DDR3_DQ11
1.5 V SSTL M14 Data bus byte lane 1
continued...
