Mechanical Drawings
A Mechanical Drawings
Ta b l e A- 1 lists the Mechanical drawings included in this appendix.
Table A-1. Mechanical Drawing List
Description Figure
Board Keepin / Keepout Zones (Sheet 1 of 2) Figure A-1
Board Keepin / Keepout Zones (Sheet 2 of 2) Figure A-2
