7.1.4.10 RdPCIConfig()
The RdPCIConfig() command provides sideband read access to the PCI configuration
space maintained in downstream devices external to the processor. The exact listing of
supported devices, functions and registers can be found in the relevant sections of the
Intel
®
Core™ i7 Processor Family for the LGA-2011 Socket Datasheet, Volume 2. PECI
originators may conduct a device/function/register enumeration sweep of this space by
issuing reads in the same manner that the BIOS would. A response of all 1s may
indicate that the device/function/register is unimplemented even with a ‘passing’
completion code. Responses will follow normal PCI protocol.
PCI configuration addresses are constructed as shown in Figure 7-39. Under normal in-
band procedures, the Bus number would be used to direct a read or write to the proper
device. All accesses to Bus0, Device[0-7] and Bus1, Device[8-15] are decoded to
registers within the processor while the remaining accesses are decoded to registers in
downstream devices.
0x0-0xF 0x040B IA32_MC2_MISC 0x0-0xF 0x0426 IA32_MC9_ADDR 0x0-0xF 0x0441 IA32_MC16_STATUS
0x0-0xF 0x040C IA32_MC3_CTL 0x0-0xF 0x0427 IA32_MC9_MISC 0x0-0xF 0x0442 IA32_MC16_ADDR
0x0-0xF 0x0283 IA32_MC3_CTL2 0x0-0xF 0x0428 IA32_MC10_CTL 0x0-0xF 0x0443 IA32_MC16_MISC
0x0-0xF 0x040D IA32_MC3_STATUS 0x0-0xF 0x028A IA32_MC10_CTL2 0x0-0xF 0x0444 IA32_MC17_CTL
0x0-0xF 0x040E IA32_MC3_ADDR 0x0-0xF 0x0429 IA32_MC10_STATUS 0x0-0xF 0x0291 IA32_MC17_CTL2
0x0-0xF 0x040F IA32_MC3_MISC 0x0-0xF 0x042A IA32_MC10_ADDR 0x0-0xF 0x0445 IA32_MC17_STATUS
0x0-0xF 0x0410 IA32_MC4_CTL 0x0-0xF 0x042B IA32_MC10_MISC 0x0-0xF 0x0446 IA32_MC17_ADDR
0x0-0xF 0x0284 IA32_MC4_CTL2 0x0-0xF 0x042C MC11_CTLIA32_ 0x0-0xF 0x0447 IA32_MC17_MISC
0x0-0xF 0x0411 IA32_MC4_STATUS 0x0-0xF 0x028B IA32_MC11_CTL2 0x0-0xF 0x0448 IA32_MC18_CTL
0x0-0xF 0x0412 IA32_MC4_ADDR 0x0-0xF 0x042D IA32_MC11_STATUS 0x0-0xF 0x0292 IA32_MC18_CTL2
0x0-0xF 0x0413 IA32_MC4_MISC 0x0-0xF 0x042E IA32_MC11_ADDR 0x0-0xF 0x0449 IA32_MC18_STATUS
0x0-0xF 0x0414 IA32_MC5_CTL 0x0-0xF 0x042F IA32_MC11_MISC 0x0-0xF 0x044A IA32_MC18_ADDR
0x0-0xF 0x0285 IA32_MC5_CTL2 0x0-0xF 0x0430 IA32_MC12_CTL 0x0-0xF 0x044B IA32_MC18_MISC
0x0-0xF 0x0415 IA32_MC5_STATUS 0x0-0xF 0x028C IA32_MC12_CTL2 0x0-0xF 0x044C IA32_MC19_CTL
0x0-0xF 0x0416 IA32_MC5_ADDR 0x0-0xF 0x0431 IA32_MC12_STATUS 0x0-0xF 0x0293 IA32_MC19_CTL2
0x0-0xF 0x0417 IA32_MC5_MISC 0x0-0xF 0x0432 IA32_MC12_ADDR 0x0-0xF 0x044D IA32_MC19_STATUS
0x0-0xF 0x0418 IA32_MC6_CTL 0x0-0xF 0x0433 IA32_MC12_MISC 0x0-0xF 0x044E IA32_MC19_ADDR
0x0-0xF 0x0286 IA32_MC6_CTL2 0x0-0xF 0x0434 IA32_MC13_CTL
0x0-0xF 0x0419 IA32_MC6_STATUS 0x0-0xF 0x028D IA32_MC13_CTL2
0x0-0xF 0x041A IA32_MC6_ADDR 0x0-0xF 0x0435 IA32_MC13_STATUS
Table 7-12. RdIAMSR() Services Summary (Sheet 2 of 2)
Processor
ID
(byte)
MSR
Address
(dword)
Meaning
Processor
ID
(byte)
MSR
Address
(dword)
Meaning
Processor
ID
(byte)
MSR
Address
(dword)
Meaning
Figure 7-39. PCI Configuration Address
31
Reserved
2728 20 19 15 1114 12 0
FunctionDevice
Bus
Register
