Thermal/Mechanical Specifications and Design Guide 71
PECI Interface
7.1.2.7.1 Package Identifier Read
This feature enables the PECI host to uniquely identify the PECI client processor. The
parameter field encodings shown in Tab le 7 - 8 allow the PECI host to access the
relevant processor information as described below.
• CPUID data: This is the equivalent of data that can be accessed through the
CPUID instruction execution. It contains processor type, stepping, model and
family ID information as shown in Figure 7-19.
• Platform ID data: The Platform ID data identifies the platform type that the
processor is being used on as per the encodings in Ta b l e 7 - 9 . The Platform ID data
can be used to ensure processor microcode updates are compatible with the
processor. Note that the value of the Platform ID or Processor Flag[2:0] as shown
in Figure 7-20 is typically unique to the platform type and processor stepping.
• Uncore Device ID: This information can be used to uniquely identify the processor
device when combined with the Vendor Identification register content. Refer to the
appropriate register description for the exact Intel
®
Core™ i7-3960X, i7-3970X
processor Extreme Edition, Intel
®
Core™ i7-3930K processor, and Intel
®
Core™
i7-3820 processor Uncore Device ID value.
Figure 7-19. CPUID Data
CPU ID Data
Model
4
20
Stepping ID
3 0
Family ID
16
Processor
Type
1931
RESERVED
27
Extended
Model
Extended
Family ID
78111228
RESERVED
1315
Table 7-9. Platform ID Encoding
Platform ID Platform Type
0x00000000 DP (Dual Processor)
0x00000001 UP (Single Processor)
0x00000002 Reserved
All Others Reserved
Figure 7-20. Platform ID Data
Platform ID Data
Processor
Flag
Reserved
2
31
0
3
