10 Intel Server Board SE7501BR2 Product Guide
Table 1. Server Board Features (continued)
Feature Description
System I/O
National Semiconductor
†
PC87417 Super I/O Controller (LPC bus) that provides
the following:
• Floppy Disk Controller
• PS/2-compatible keyboard and mouse ports, 6-pin DIN connectors
• Advanced parallel port, supporting Enhanced Parallel Port (EPP) level 1.7
and 1.9, ECP, compatible 25-pin connector
• Two serial ports: One a-synch 9-pin RS-232C, one via 10-pin internal
connector
Two Ethernet controllers via RJ45 connectors: one Intel Fast Ethernet 82550PM,
one Intel Gigabit 82540EM
Five USB ports: three stacked USB connectors in I/O rear panel, two via 10-pin
internal header
Power • SSI-EEB 3.0 compliant
• Power/Sleep Switch with LED Indicator
• Wake on LAN
†
(WOL)
• Wake on Ring (WOR)
Security • BIOS password
• Keyboard password protection
• Floppy write-protect
Form Factor • SSI-EEB 3.0 compliant form factor
Server Management
1
IPMI 1.5 compliant
Intel® Baseboard Management Controller (BMC)
Intel® Server Management (ISM) software Version 5.5, including support for:
• Hardware health monitoring through system sensors
• Proactive, alert notification through email, LAN and paging devices
• Remote access and diagnostics
• System Event Log manager
• Sensor Data Records manager
• Field Replaceable Unit manager
• Remote Sensor Access manager
• BIOS Console redirection
• Remote Configuration/Setup
• Serial over LAN
• Command Line Interface over LAN
• Server Configuration Wizard (SCW)
• Intel® SMaRT Tool Integration
• Online Rolling BIOS & Firmware Upgrade
• Command Line Interface over LAN
• ID LED Server Management Support
1
For additional information refer to the Intel® Server Management ver 5.5 Installation & User’s Guide
available on the ISM CD.
