Chapter 14: Device management

TruVision DVR 12HD User Manual 103

Option Description

Interface

Select one of the three ways the RS-232 port can be used:

ProBridge: POS and ATM text insertion supported via the ProBridge

accessory connected to the RS-232 port. See “Text insertion” on page 101

for more information.

Challenger: NTP time sync supported to foreign device over the RS-232

port.

Technical Support: Console mode.
