Appendix E: KTD-405 keypad
TruVision DVR 12HD User Manual 145
6. Move the cursor to the Enter button on the soft keyboard and press Enter
( ) on the KTD-405 keypad to quit the soft keyboard.
7. Press and hold esc and then press the arrow buttons to navigate the cursor to
activate OK button on the Login screen.
8. Press . The main menu appears.
Example 2: To modify a menu option using the keypad
1. In the main menu press and hold esc and then press the arrow buttons to navigate
to the desired menu icon (for example, Display Mode Settings).
2. Press esc and to go to Display Mode Settings menu.
3. Press Zoom + or Zoom - to scroll to the menu tab, More Settings.
4. When in the desired menu window, press and hold esc and then press the arrow
buttons to navigate the cursor to the option, Menu Timeout.
5. Press to activate the dropdown menu.
6. Press and hold esc and then press the up/down arrow buttons to navigate to the
desired option.
7. Press to select the option.
8. Press and hold esc and then press the up/down arrow buttons to navigate to Apply.
Press to select it. Then navigate to Back to return to live view.
Instead of the arrow buttons, you can also use the joystick on the keyboard.
Recorder mapping to the KTD-405 keypad
Table 22: Recorder mapping to the KTD-405 keypad
Task Keypad action Further information
Menu mode
Call up or exit menu In live view, press esc. To log out the menu: go to the Power
Manager menu and select Logout.
Move through the menus Press and hold esc and
then press the arrow
buttons or use the joystick.
Down, Up, Left, Right
Move between menu tabs Press seq to switch
between menu tabs.
Navigate to a menu option Press and hold esc and
then press the arrow
buttons or use the joystick.
Down, Up, Left, Right
Select a character or menu
option
Press Enter ( ). Note. If you press esc before pressing
Enter, you quit the menu without saving
any changes. It is the same as Cancel.
Select the zone ID Press zone to connect the
keypad to the recorder.
