Chapter 10: Camera setup
60 TruVision DVR 12HD User Manual
Analog camera setup
The recorder can support up to 16 cameras depending on the model, which can be a
mix of analog and IP cameras. By default, all camera channels in the recorder are
analog. You need to disable analog cameras in order to add IP cameras. However, at
least half of the camera channels will always be analog.
You can quickly see an overview of all the analog cameras and their status in the
Analog Camera Overview screen (see Figure 19 below). The number of cameras
displayed depends on the recorder model. You can also select a camera to live view
the image.
When an analog camera is enabled or disabled, the system must reboot for the
changes to take effect.
Figure 19: Overview of analog cameras window (4-channel recorder model shown)
List of all the analog channels (number depends on
To enable or disable an analog camera:
1. From the menu toolbar, click Camera Setup > Analog Camera Overview.
2. In the Status section, check the boxes of the cameras that you want to enable.
Uncheck those you want to disable in order to add an IP camera.
3. Click Apply to save the changes.
4. A pop-up message will appear asking if you want to reboot the system. Click Yes.
