Interlogix TruVision - Appendix A Specifications

132 TruVision DVR 12HD User Manual
Appendix A
Specifications
TVR 1204HD TVR 1208HD TVR 1216HD
Video
& audio input
Video compression
H.264
Analog video input
4-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC self-
adaptive
8-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC self-
adaptive
16-ch,
BNC
(1.0 Vp-p, 75 Ω),
PAL /NTSC self-
adaptive
Audio compression
G711u
Audio input
4-ch, RCA (2.0 Vp-p, 1 kΩ)
Two
-way audio 1-ch (reduplicated with audio input 1), RCA (2.0 Vp-p, 1 kΩ)
Video & a
udio output
HDMI output
1-ch,
Resolution: 1920 × 1080P / 60 Hz, 1280 × 1024 / 60 Hz,1280 × 720 / 60 Hz,
1024 × 768 / 60 Hz
VGA output
1-ch,
Resolution: 1920 × 1080P / 60 Hz, 1280 × 1024 / 60 Hz,1280 × 720 / 60 Hz,
1024 × 768 / 60 Hz
Analog output
1-ch, BNC (1.0 Vp-p, 75 Ω),
Resolution: PAL: 704 × 576; NTSC: 704 × 480
Video loop output
4-ch 8-ch 16-ch
Encoding resolution
Main stream: 1080P (non-real time) / 720P / VGA / WD1 / 4CIF / CIF
Substream: WD1 (non-real time) / 4CIF (non-real time) / CIF / QCIF / QVGA
Video bit rate
32 Kbps to 6 Mbps
Audio output
1-ch, RCA
Audio bit rate
64 Kbps
Dual
-stream Support | (Sub-stream at CIF: 6 fps,
QCIF: 25 fps (PAL) / 30 fps (NTSC))
Stream
type Video, Video & Audio
Playback resolution
4CIF / 2CIF / CIF / QCIF
Synchronous playback
4-ch 8-ch 16-ch
