Interlogix TruVision User Manual

Chapter 9: Display settings
TruVision DVR 12HD User Manual 57
Option Description
2.
Picture Setting
Define the desired output mode.
Select one of the options from the drop-down list: Standard, Bright, Soft,
or Vivid, and click Apply.
3.
BNC Output Brightness
Modify the video output brightness.
Adjust the scroll bar point to the desired level and click Apply.
4.
Resolution
Define the resolution of the selected monitor.
Select one of the options from the drop-down list and click Apply. The
selected resolution must be the same as that of the monitor.
5.
Display Status Icons
Define whether the status icons are displayed. Default is Enable.
6.
Timebar Transparent
Select the transparency of the monitor output time bar on
screen relative
to the background to make the time bar easier to read.
Check the box to enable/disable. Default is Disable.
7.
Enable
Timebar Select whether the monitor output time bar appears on screen.
Check the box to enable/disable. Default is Enable.
8.
Video Output Interface
Select the desired video output interface to apply: Main BNC or
VGA/HDMI. Default is VGA/HDMI.
9.
Default View
The factory default multiview format displays all channels (2x2 layout for
the 4-channel TVR 12HD and 4x4 layout for the 8/16-channel TVR
12HD).
10.
Sequence Dwell Time
Set the length of time for which a camera image is displayed on the
selected monitor before moving to the next camera during sequencing.
Default is off (“No Switch”).
11.
Enable Audio Output
Select whether to hear audio from cameras in both live and playback
mode. However, in order to be able to hear audio in playback, you must
enable the audio output setting. Default is Disable.
Check the box to enable/disable audio output.
12.
Event Monitor
Select which monitor will be the event monitor showing full screen
monitoring in case of events: HDMI/VGA, or Main BNC. Default is Main
analog.
13.
Event Full Screen
Monitoring Dwell Time
Set the length of time during which an image is displayed on the event
monitor in full screen in case of an event. Default is 10 seconds.
14.
Alarm Full Screen
Monitoring Dwell Time
Set the length of time during which an image is displayed on the event
monitor in full screen in case of an alarm. Default is 10 seconds.
15.
Audio Output Linked to
Select from which monitor (Main BNC or VGA) audio can be heard.
Layout
The Layout window allows you to define the layout of each of the different views as they
are shown when selecting the different live views or the sequencing order.
The cameras are sequenced in numeric order by default. You can change the order of
the cameras for all monitors.
