Chapter 18: Using the web browser
TruVision DVR 12HD User Manual 125
Play back recorded video
To search and play back recorded video, click Playback on the menu bar to display the
Playback page shown in Figure 32 below.
Figure 32: Browser playback page
. Calendar: Selected day is highlighted.
. Search: Click to start searching recorded files for the selected camera.
. Display format: Click to change the display format in the viewer: single view or multiview display.
. Timeline: The timeline moves left (oldest video) to right (newest video). Click a location on the
timeline to move the cursor to where you want playback to start.
. Playback control toolbar:
Reverse: Click to reverse playback.
Start/stop: Start or stop playback.
Stop playback. Timeline jumps back to 00:00:00 time (midnight) of the previous day.
Speed down: Click to scroll through the different speeds available: single frame, 1/8
speed, ¼ speed, ½ speed, normal, X2 speed, X4 speed, X8 speed, maximum speed.
Current speed is displayed under the camera name on top right of window.
Speed up: Click to scroll through the different speeds available: single frame, 1
speed, ½ speed, normal, X2 speed, X4 speed, X8 speed, maximum speed. Current speed
is displayed under the camera name on top right of window.
Single frame: Click to play back one frame at a time.
Stop streaming: Stop streaming from all cameras.
