Appendix A: Specifications
TruVision DVR 12HD User Manual 133
TVR 1204HD TVR 1208HD TVR 1216HD
Hard disk
SATA
1 SATA interface 2 SATA interfaces
Capacity
Up to 4TB capacity for each disk
External interface
Network interface
1 RJ45 10M / 100M self-adaptive Ethernet
interface
1 RJ45 10M / 100M /
1000M self-adaptive
Ethernet interface
Serial interface
1 RS-232 interface (for ProBridge, Challenger, Technical Support);
1 RS-485 interface (for PTZ control or KTD405 keyboard control)
USB interface
2, USB 2.0
Alarm in
4
Alarm out
1
Miscellaneous
Power supply
12 VDC
Power consumption
(without HDD or DVD
-R/W)
≤ 15 W ≤ 20 W ≤ 20 W
Operating temperature
-10 to +55 ºC (14 to 131 °F)
Relative humidity
10 to 90%
Chassis
1U chassis 380 mm 1chassis
Dimensions (W x H x D)
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 in.) 380 × 290 × 48 mm
(15.0 × 11.4 × 1.9 in.)
Weight
≤ 1.5 kg (3.3 lb.) ≤ 2 kg (4.4 lb.)
