Chapter 15: Storage management
106 TruVision DVR 12HD User Manual
3. Select a camera whose storage capacity you want to change and enter the values in
GB for the maximum record capacity and snapshot capacities. The available quota
space available is displayed on screen.
4. Click Apply to save the settings.
5. If you want to copy these values to other cameras, click Copy and select each
camera individually. Click OK. Click Apply to save the settings.
Group HDDs
Your recorder can organize multiple HDDs into groups. Videos from specified channels
can be set to be recorded onto a particular HDD group. You could, for example, save
the records from a couple of high priority cameras to one HDD, and save the recordings
from all the other cameras to another HDD.
To set up an HDD group:
1. From the menu toolbar, click Storage Management > Storage Mode.
2. Under Mode, select Group.
3. Under Record on HDD Group, select a number for the HDD group.
4. Check the channels to be added to this group.
Note: By default, all channels belong to HDD group 1.
5. Click Apply to save the settings.
6. Continue to configure the recorder or click Exit to return to live view.
Create HDD groups
If you have more than one HDD installed, you can change the behavior of a HDD by
changing its property. It can be set to read-only or read/write (R/W). The storage mode
must be set to Group before setting the HDD property.
A HDD can be set to read-only to avoid important recorded files from being overwritten
when the HDD becomes full.
To change a HDD status property:
1. From the menu toolbar, click Storage Management > HDD Information.
2. Select the HDD whose property you want to change.
3. Click the Edit icon . The Local HDD Settings window appears.
Note: The Edit icon is only available if there are at least two HDDs installed.
4. Click the desired HDD property for the selected HDD: R/W or Read Only.
5. Click the group number for this HDD.
6. Click Apply to save and exit the window.
