Intermec EasyCoder 201 II – Technical Manual
SETUP PARAMETERS
The setup allows you to adapt the printer for the desired type of
computer communication and to control the printing. The setup
parameters are:
General Information
Parameter Options Default
1
❑ Contrast Variable (0–10) Middle (5)
❑ Ser-Com
2
:
◆ Baudrate 300 | 600 | 1200 | 2400 | 4800 | 9600 | 19200 | 38400
3
9600
◆ Parity even | odd | mark | space | none none
◆ Char length 7 bits | 8 bits 7 bits
◆ Stop bits 1 bit | 2 bits 2 bits
◆ Type of flow control:
- RTS/CTS Enable | disable (not on "uart2:" when RS 485 interface pcb fitted) disable
- ENQ/ACK Enable | disable disable
- XON/XOFF, data from host Enable | disable enable
- XON/XOFF, data to host Enable | disable enable
- Prot addr. Enable | disable ("uart2:" only, when RS 485 interface pcb fitted) disable
◆ New line CR/LF | LF | CR CR/LF
❑ Detection:
◆ LSS adjust Variable n.a.
◆ Feed adj:
- Start adjust Variable ± 0
- Stop adjust Variable ± 0
❑ Service:
◆ Media size:
- X-start Variable (6 dots/mm: 0–511; 8 dots/mm: 0 – 639) 0/0
- Width Variable (6 dots/mm: 0–512; 8 dots/mm: 0 – 640) 512/640
- Length Unlimited 1200/1200
◆ Media type: Label (w gaps) | Ticket (w mark) | Ticket (w gaps) |
Fix length strip | Var length strip Label (w gaps)
◆ Print defs:
- Head resist Set automatically at startup n.a.
- Paper type See the chapter “Thermal Paper” RICOH 130LAB/LAM
- Test print A series of test labels can be printed
4
n.a.
◆ Performance: Normal | High | Ultra high Normal
◆ Memory alloc:
- Image buff size Variable (max. 250 kbyte) 24 kbyte
5
- Rec buff size
2
Variable 300 byte
5
- Trans buff size
2
Variable 300 byte
1
/. “Default” refers to the default setup values in the standard configuration EPROM's. A custom-made printer fitted with
nonstandard configuration EPROM's may have a different combination of setup values.
2
/. The software is able to detect if any of the optional serial interface boards is fitted. If so, the communication parameters
and the size of the buffers are set up separately for each of the serial communication channels "uart1:", "uart2:", and
"uart3:". There is no communication setup for the optional Centronics parallel communication channel.
3
/. Baudrate 38,400 is only available for "uart2:" and "uart3:" (requires an optional interface board).
4
/. Not available for EasyCoder 201 IIS.
5
/. Higher default value for EasyCoder 201 IISA.
