Connector configuration
The connector is the standard female 36-pole Centronics type. The
mounting holes are connected to chassis ground.
Note:
The PE signal (Paper End) on pin 12 requires an error-trapping
routine to be included in the Intermec Fingerprint software, activat-
ing the BUSY and READY statements. Here is an example on how
such a routine may be written:
10 IF (PRSTAT AND 4) THEN GOSUB 1000
20 IF (PRSTAT AND 4) = 0 THEN GOSUB 2000
. . . .
. . . .
. . . .
1000 BUSY4
1010 RETURN
2000 READY4
2010 RETURN
Also see BUSY and READY statements and PRSTAT function in the
Intermec Fingerprint manuals.
INTERFACES, cont'd.
Parallel Interface Board,
cont'd.
Pin Signal Dir. Remarks
1 /STROBE In
2 DATA 0 In
3 DATA 1 In
4 DATA 2 In
5 DATA 3 In
6 DATA 4 In
7 DATA 5 In
8 DATA 6 In
9 DATA 7 In
10 ACK Out
11 BUSY Out
12 PE Out See note!
13 SELECT Out
14–15 – – not used
16–17 GND
18 + 5V Out If strap fitted on P-2. Max. 200 mA.
19–30 GND
31 /INPRM In
32 /ERROR Out
33–35 – – not used
36 /SLCTIN In
37–38 GND Housing
Intermec offers a 3 metres (9.8 ft.) long
ready-made parallel communication
cable (36-p male Centronics – DB25
male).
Part No. 1-010001-00
