Intermec EasyCoder 201 II – Technical Manual
Setup Mode Overview, Part 2
SETTING UP EASYCODER 201 IIE & 201 IISA, cont'd.
VAR LENGTH STRIP
FIX LENGTH STRIP
TICKET (w GAPS)
TICKET (w MARK)
SETUP:
SERVICE
SETUP:
PASSWD:
SERVICE:
MEDIA SIZE
A series of test labels is printed in a loop.
If printer is unable to print a test label, press F5/–>
key for a status report.
• Press F4/<– to return to the “Detection” menu in part 1.
• Press F5/–> key to return to “Media Size” menu.
• Press Setup/Save key to exit the Setup Mode.
MEDIA SIZE:
XSTART
XSTART:
[0]:
MEDIA SIZE:
WIDTH
WIDTH:
[640]:
MEDIA SIZE:
LENGTH
LENGTH:
[1200]:
SERVICE:
MEDIA TYPE
MEDIA TYPE:
LABEL (w GAPS)
SERVICE:
PRINT DEFS
PRINT DEFS:
HEAD RESIST
HEAD RESIST:
[nnn]: Measured
PRINT DEFS:
PAPER TYPE
(designation)
(designation)
PAPER TYPE:
(designation)
PRINT DEFS:
TESTPRINT
<PRINT> = PRINT
<C> = EXIT
ULTRA HIGH
HIGH
SERVICE:
PERFORMANCE
PERFORMANCE:
NORMAL
SERVICE:
MEMORY ALLOC
MEMORY ALLOC:
IMAGE BUFF SIZE
IMAGE BUFF SIZE:
[24Kb]:
MEMORY ALLOC:
REC BUF UART1
REC BUF UART1:
[300]:
MEMORY ALLOC:
TRANS BUF UART1
TRANS BUF UART1:
[300]:
MEMORY ALLOC:
REC BUF UART2
REC BUF UART2:
[300]:
MEMORY ALLOC:
TRANS BUF UART2
TRANS BUF UART2:
[300]:
MEMORY ALLOC:
REC BUF UART3
REC BUF UART3:
[300]:
MEMORY ALLOC:
TRANS BUF UART3
TRANS BUF UART3:
[300]:
Password: 1138
Value is read only
Printhead resistance is set up
automatically at start-up.
Refer to the chapter “Thermal paper”
fo a list of available setup options.
These menus are only displayed if an optional
interface board with at least one serial
communication channel is fitted
