Intermec EasyCoder 201 II – Technical Manual
SETUP PARAMETERS, cont'd.
Print Window:
8 dots/mm (203.2 dpi) printhead
PAPER FEED
DIRECTION
Dot 0
Dot-line
on printhead
X-start Width
Origin
Dot 639
Length
7" INTERNAL "BIG ROLL”
Dot 16
3.0 mm (0.12") 6.0 mm (0.24")
PRINT
WINDOW
80.0 mm (3.15")
78.0 mm (3.07")
5.0 mm (0.20")
89.0 mm (3.50")
80.2 mm (3.16")
