Appendix C — Setup Parameters (Fingerprint)
94 EasyCoder PD42 Printer User’s Guide
It is important to select the correct media type, so the printer can
communicate the following error:
• Error 1005 “Out of paper” indicates that the last ordered copy
could not be printed because of an empty media stock.
• Error 1031 “Next label not found” indicates that the last
ordered label or ticket was successfully printed, but no more
labels/tickets can be printed because of an empty media stock.
Paper Type
The Paper Type parameters control the heat emitted from the
printhead to the direct thermal media or, optionally, the transfer
ribbon in order to produce the dots that make up the printout
image.
Labels, tickets, tags, strip, and ribbons for various types of
application are available from Intermec. To attain optimal
printout quality and extending the life of the printhead, use
Intermec supplies.
As a general rule, high energy and/or high print speed will
shorten the life of the printhead. Never use incorrect paper type
settings or higher print speed settings than necessary for
obtaining an acceptable printout quality and throughput speed.
If the ambient temperature is lower than +15°C (+59°F), decrease
the print speed by 50 mm/sec.
Start by choosing between two alternatives:
• Direct Thermal printing (option)
• Thermal Transfer printing (default)
Your choice will decide which parameters to enter next:
Direct Thermal Printing
• Label Constant (range 50 to 115). Default is 85.
• Label Factor (range 10 to 50). Default is 40.
Note: It is highly recommended to use PrintSet 4 to set the Paper
Type setup parameters. PrintSet 4 includes a Print Quality
Wizard that guides you through the process of improving
printout quality.
