Intermec PC43d User Manual

Chapter 5 — Troubleshoot the Printer
108 PC23 and PC43 Desktop Printer User Manual
Restore Defaults on the Printer
You can restore the printer defaults by performing a hardware-based
reset.
1 Turn the printer off.
2 Pull one or both of the printer latches forward and lift the printer
lid.
3 Turn the printer on.
4 For an icon printer, watch the icon panel. When the bottom row of
icons turns off, press and hold
, and release when the
icon begins flashing.
For an LCD printer, watch the startup progress bar. When the bar
is halfway across the screen, press and hold
, and release
when the first screen of the Startup Wizard appears.
5 Close the printer lid. The defaults are restored. For an LCD printer,
follow the instructions in the Startup Wizard.

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
