Intermec PC43d User Manual

Appendix B — Default Settings
152 PC23 and PC43 Desktop Printer User Manual
System I/O Settings
This section describes system I/O settings for the printer. To view these
settings:
• From the printer Main Menu, select Settings > System Settings >
Manage I/O.
• From the printer web page, click the Configure tab, System
Settings > Manage I/O.
New Line Character Defines the characters that the printer
echoes to the host to indicate that it has
moved to a new line.
CR/LF
Serial Port Settings (Continued)
Setting Description Default
System I/O Settings
Setting Description Default
Wireless 802.11 Determines if the printer is allowed to
communicate using its 802.11 radio.
Supported only if the optional
Wi-Fi+Bluetooth module is installed.
Enable
Bluetooth Determines if the printer is allowed to
communicate using its Bluetooth radio.
Supported only if the optional
Wi-Fi+Bluetooth module is installed.
Enable
RFID Determines if the printer is allowed to
communicate using its RFID radio. Supported
only if the RFID module is installed.
Enable
Virtual COM Determines if you can enable the USB port to
be used as a virtual serial port.
Disable

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
