Appendix A — Specifications
124 PC23 and PC43 Desktop Printer User Manual
Printer Specifications
PC23d Physical Specifications
Dimensions: 17.7 cm x 12.5 cm x 21.5 cm
(6.97 in x 4.92 in x 8.46 in)
Weight: 1.45 kg (3.20 lbs)
Power Supply Requirements: 100–240 VAC, 50–60 Hz, 60W
Operating Temperature: 5 °C to 40 °C (41 °F to 104 °F)
Storage Temperature: -40 °C to 60 °C (-40 °F to 140 °F)
Relative Humidity: 20 to 80% non-condensing
PC23d Print Speed, Resolution, and General Media Specifications
Print Mode: Direct thermal
Print Speed (variable): 203 dpi: 50 to 200 mm/sec (2 to 8 ips) 300
dpi: 50 to 150 mm/sec (2 to 6 ips)
Print Resolution: 203 dpi: 8 dots/mm300 dpi: 11.8
dots/mm
Print Width: 203 dpi: 54 mm (2.1 in) max 300 dpi: 56
mm (2.2 in) max
Media Width: 15 to 60 mm (0.59 to 2.36 in)
Label Roll Diameter (maximum): 127 mm (5 in)
Label Length (minimum): 6.35 mm (.25 in)
Gap Length Between Labels: 2 to 10 mm (0.08 to 0.39 in)
Black Mark Length 3 to 10 mm (0.12 to 0.39 in) centered
between tickets, 15% maximum
reflectance
Media Thickness: 76.2 to 203 μm (3 to 8 mil), flexible
wristbands up to 10 mils (maximum)
Media Density:
60 to 181 g/m
2
Liner Opacity (maximum): 76% (TAPPI T425)
Label Stop Sensor Adjustable from left media edge to 4.5
mm right of center on LCD printers
(fixed at center on Icon printers)

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
