Intermec PC43d User Manual

Chapter 1 — About the Printers
PC23 and PC43 Desktop Printer User Manual 31
3 Connect the battery base to AC power.
The battery begins to charge and the battery base LEDs turn on to
indicate charge status. The battery is fully charged in 4
hours.
Power the PC43d with the Battery Base
After you charge the battery, you can use the battery base accessory to
power the PC43d printer. When the battery base is not connected to
AC power, press the Charge Level button on the front of the base to
turn on the LEDs and see the current charge level.
1 Charge the battery in the battery base.
2 Disconnect the power cable from AC power.
-&%T

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
