Chapter 1 — About the Printers
6 PC23 and PC43 Desktop Printer User Manual
About the Front Panel
There are two front panels available for the printers:
LCD (liquid crystal display)
Icon (no display)
Both versions of the front panel contain the Print button and the
Ready-to-Work™ indicator. Printers with the LCD also have a USB
host port on the front panel.
About the Ready-to-Work Indicator
The Ready-to-Work indicator on the front of the printer turns on
when the printer is ready to print.
Ready-to-Work Indicator Location
Ready-to-Work Indicator Status
Ready-to-Work Indicator Status Description
On Printer is ready for a print job.
Blinking Printer is not ready for a print job.
3FBEZUP8PSL
JOEJDBUPS

Table of Contents

Other manuals for Intermec PC43d

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intermec PC43d and is the answer not in the manual?

Intermec PC43d Specifications

General IconGeneral
Print TechnologyDirect Thermal
Print Resolution203 dpi (8 dots/mm)
Max Print Width4.1 inches
Max Print Speed8 ips
ConnectivityUSB, Serial, Ethernet
Media Handlingfanfold
Memory128 MB Flash, 64 MB SDRAM
Media TypeTags
Roll Maximum Outer Diameter5 inches
Core Diameter1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature+5°C to +40°C (+41°F to +104°F)
Storage Temperature-20°C to +60°C (-4°F to +140°F)
Humidity10 to 90% RH non-condensing
Power Requirements100-240V AC, 50-60 Hz
