Intermec PC43d User Manual

Chapter 4 — Configure the Printer
PC23 and PC43 Desktop Printer User Manual 85
How to Configure the Printer
Use one of these methods to view and change printer settings:
• Printer web page
• Main Menu (LCD printers)
• PrintSet 5
• Programming commands
• SmartSystems
View the Configuration Summary
If you are using Ethernet or Wi-Fi communications, you can view a
complete summary of all printer configuration settings from the
printer web page. You should have already connected your printer to
your network and obtained an IP address.
1 Open a web browser on your PC.
2 In the Location or Address bar, type the printer IP address, and
then press Enter. The printer web page appears.
3 Click the Configure tab.
Note: This may take several minutes depending on the options in your
printer and your network connection.

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
