Intermec PC43d User Manual

Chapter 2 — Set Up the Printer
PC23 and PC43 Desktop Printer User Manual 61
Print a Test Label in Start Up Mode
You can print a test label when you first turn on the printer.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 Connect the printer to power and turn on the printer.
3 On the icon printer, when the last two LEDs are lit (Maintenance
and Bluetooth), press and hold
until the test label starts to
print.
On the LCD printer, when the status bar appears, press and hold
until the Media Calibration Wizard appears. Select and
press to print a label with the current print settings.
Print a Test Label in Idle Mode
You can print a test label when the printer is in Idle mode.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 On the icon printer, press and hold until the test label starts to
print.
On the LCD printer, press and hold until the Media
Calibration Wizard appears. To print a label with the current print
settings, select
and press .
Print a Test Label from the Main Menu
If you have an LCD printer, you can print a test label from the Main
Menu.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 From the Ready screen, press .

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
