Intermec PC43d User Manual

Chapter 2 — Set Up the Printer
48 PC23 and PC43 Desktop Printer User Manual
About the Label Dispenser
The label dispenser accessory, which includes the Label Taken Sensor,
removes the liner from self-adhesive label stock as each label is printed.
You manually remove the label at the front of the printer.
After you load media, you need to configure the feed adjust settings.
You may need to adjust the recommended values slightly depending
on your media type, supply method, and roll sizes, or because of
individual differences between printers.
Note: Feed adjust values for simulator command languages like ESim,
ZSim, and DSim are preset.
Recommended Feed Adjust Values for the Label Dispenser
Printer Setting 203 dpi 300 dpi Distance
PC23d Start Adjust -117 -173 -14.70 mm (-0.58 in)
Stop Adjust 3 5 -0.46 mm (0.02 in)
PC43d Start Adjust -126 -186 -15.8 mm (-0.62 in)
Stop Adjust 2 3 0.3 mm (0.01 in)
PC43t Start Adjust -125 -185 -15.7 mm (-0.62 in)
Stop Adjust 16 24 2.1 mm (0.08 in)

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
