Intermec PC43d User Manual

Chapter 1 — About the Printers
28 PC23 and PC43 Desktop Printer User Manual
About the Battery Base
Instead of using the AC power supply, you can use the optional battery
base to provide power for the PC43d printer. Depending on your
printer duty cycle, the rechargeable battery in the battery base provides
up to 8 hours of power.
PC43d Printer and Battery Base
For help installing the printer on the battery base, see the PC43d
Battery Base Installation Instructions.
Note: Battery life depends on many factors. The battery is designed to
provide 8 hours of charge (plus one hour of standby time) when you
are printing a 150-mm (6-in) label every 7 minutes.
Note: Printing speed depends on the actual battery charge level. The
maximum print speed for a PC43d running on battery power is 6 ips
for 203 dpi and 4 ips for 300 dpi.

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
