Intermec PC43d User Manual

Appendix B — Default Settings
150 PC23 and PC43 Desktop Printer User Manual
Print Quality Settings
This section describes print quality settings. To view these settings:
• From the printer Main Menu, select Settings > Printing > Print
Quality.
• From the printer web page, click the Configure tab, Printing >
Print Quality.
Length (Slow
Mode)
If Media Calibration Mode is set to Slow,
the printer prints the media length plus 10
mm. This value sets an additional amount
of media to be printed. Unit of
measurement is defined in the Unit of
Measurement parameter. Range is 0 to
3200.
0
LTS
Sensitivity
Level
Sets the sensitivity of the label taken sensor.
Range is 0 to 14. Supported when the
Cutter or Label Dispenser accessories are
installed.
0
Media Settings (Continued)
Setting Description Default
Print Quality Settings
Setting Description Default
Print Speed Sets how fast the printer prints labels. The
unit of measure is defined in the Unit of
Measure parameter.
100
Media Sensitivity Sets the level of sensitivity of the media to the
printhead heat for media and ribbon.
Variable
Darkness Sets the image darkness for media and ribbon.
Adjust this parameter with the Media
Sensitivity parameter. Range is 1 to 100.
Variable
Contrast Adjusts the blackness of the printing on the
label in 2% increments from -10% to +10%.
+0%

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
