Chapter 2 — Set Up the Printer
PC23 and PC43 Desktop Printer User Manual 63
About RFID Tag Position
Tag Position, also referred to as TAGADJUST, specifies the distance (in
dots/mm/in) to move the label to align the tag with the RFID antenna.
Positive values move the label forward, and negative values move the
label back.
RFID Tag Position
Use one of these methods to calculate Tag Position:
Run the RFID wizard.
Manually calculate the Tag Position.
Run the RFID Calibration Wizard
Run the RFID calibration wizard to determine the best Tag Position
and Output Power (UHF inlays, only) for RFID media.
5BHQPTJUJPO
$FOUFS
PGUBH
.FEJBFEHF
5FBSCBS
3'*%DIJQ
3'*%BOUFOOB
Note: After you determine the correct RFID media settings, you can
save these settings to a printer profile and load the profile when you
need to print on the specific RFID media.
