Chapter 1 — About the Printers
PC23 and PC43 Desktop Printer User Manual 21
Set the Command Language from the Main Menu
If you have an LCD printer, you can change the printer command
language from the Main Menu.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 From the Ready screen, press . The Main Menu appears.
3 In the Main Menu, select Settings > System Settings > General.
4 In the General settings list, press to scroll to Command
Language.
5 Press or to select a different command language.
6 Press or .
7 Press to save your changes.
If you are prompted to enter a password for ZSim, the password is
1138. To return to the Fingerprint menu system from ZSim, the
password is 8311.
Set the Command Language with the Print Button
If you have an icon printer, you can use the Print button to set the
printer command language.
1 Make sure that the printer has media and ribbon (if necessary)
installed.
2 Turn off the printer.
3 Turn the printer back on. All the LEDs light up. As the printer
starts up, the LEDs turn off one by one, starting with the bottom
right LED.
4 When the last two LEDs (Maintenance and Bluetooth) are lit, press
and hold
. The printer feeds a few labels as it automatically
adjusts the media feed, and then the test labels start to print.
5 Continue to hold . The available printer command languages
start to print.

Table of Contents

Other manuals for Intermec PC43d

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Intermec PC43d and is the answer not in the manual?

Intermec PC43d Specifications

General IconGeneral
Print TechnologyDirect Thermal
Print Resolution203 dpi (8 dots/mm)
Max Print Width4.1 inches
Max Print Speed8 ips
ConnectivityUSB, Serial, Ethernet
Media Handlingfanfold
Memory128 MB Flash, 64 MB SDRAM
Media TypeTags
Roll Maximum Outer Diameter5 inches
Core Diameter1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature+5°C to +40°C (+41°F to +104°F)
Storage Temperature-20°C to +60°C (-4°F to +140°F)
Humidity10 to 90% RH non-condensing
Power Requirements100-240V AC, 50-60 Hz
