Intermec PC43d User Manual

Chapter 1 — About the Printers
PC23 and PC43 Desktop Printer User Manual 11
View Basic Printer and Connection Information
In the Ready screen, use the control panel buttons to select an icon in
the status bar at the top of the screen to view printer or connection
information.
1 Press any arrow key to select the one of the icons in the status bar
at the top of the Ready screen.
2 Press . A list of basic printer or connection information appears.
3 Press or to scroll through the list.
(Optional) Press or to view information for one of the other
icons.
4 Press or to return to the Ready screen.
Fingerprint
10.200.27.89
01/04/2012
12:00
®
1SJOUFSJOGPSNBUJPO
JDPOTFMFDUFE
4UBUVTCBS
Ready
A0000000000000002
S0000000411
PC43t
Firmware Version:
Product Name:
Printer Serial Number:
Printer Configuration Number
Printing

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
