Chapter 1 — About the Printers
PC23 and PC43 Desktop Printer User Manual 29
Battery Base LEDs
When the battery base is connected to AC power, the LEDs indicate the
battery charge status.
When the battery base is not connected to AC power, you can press the
Charge Level button to briefly turn on the LEDs and see the battery
charge level.
LEDs: Battery Base Connected to AC Power
LEDs Battery Charge Status
95% to 100%
76% to 94%
51% to 75%
26% to 50%
0% to 25%
Battery out of charging temperature
range.
Battery error.
LEDs: Battery Base Not Connected to AC Power
LEDs Battery Charge Level
Battery is 76% to 100% charged.
Battery is 51% to 75% charged.
Battery is 26% to 50% charged.
Battery is 11% to 25% charged.

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
