Appendix A — Specifications
PC23 and PC43 Desktop Printer User Manual 125
PC43d Physical Specifications
Dimensions: 16.8 cm x 18.0 cm x 21.5 cm
(6.61 in x 7.09 in x 8.46 in)
Weight: 1.72 kg (3.80 lbs)
Power Supply Requirements: 100–240 VAC, 50–60 Hz, 60 W
Operating Temperature: 5 °C to 40 °C (41 °F to 104 °F)
Storage Temperature: -40 °C to 60 °C (-40 °F to 140 °F)
Relative Humidity: 20 to 80% non-condensing
PC43d Print Speed, Resolution, and General Media Specifications
Print Mode: Direct thermal
Print Speed (variable): 203 dpi: 50 to 200 mm/sec (2 to 8 ips) 300
dpi: 50 to 150 mm/sec (2 to 6 ips)
Print Speed (on battery power): 203 dpi: 50 to 150 mm/sec (2 to 6 ips) 300
dpi: 50 to 100 mm/sec (2 to 4 ips)
Print Resolution: 203 dpi: 8 dots/mm300 dpi: 11.8
dots/mm
Print Width: 203 dpi: 104 mm (4.09 in) max 300 dpi:
106 mm (4.17 in) max
Media Width: 19.05 to 118 mm (0.75 to 4.65 in)
Label Roll Diameter (maximum): 127 mm (5 in)
Label Length (minimum): 6.35 mm (0.25 in)
Gap Length Between Labels: 2 to 10 mm (0.08 to 0.39 in)
Black Mark Length 3 to 10 mm (0.12 to 0.39 in) centered
between tickets, 15% maximum
reflectance
Media Thickness: 76.2 to 203 μm (3 to 8 mil)
Media Density:
60 to 181 g/m
2
Liner Opacity (maximum): 76% (TAPPI T425)
Label Stop Sensor Adjustable from left media edge to
4.5
mm right of center on LCD printers
(fixed at center on Icon printers)
