Intermec PC43d User Manual

Chapter 1 — About the Printers
4 PC23 and PC43 Desktop Printer User Manual
PC43d Front Panel (Icon Model)
PC43d Rear Panel
-BUDI
3FBEZUP8PSL
JOEJDBUPS
1SJOUCVUUPO
*DPOQBOFM
.FEJBXJOEPX
1PXFSQPSU
64#EFWJDFQPSU
64#IPTUQPSU
&UIFSOFUQPSU
PQUJPOBM
1PXFS
TXJUDI
1SJOUFS
MPDLJOH
DBCMFTMPU
&YUFSOBMNFEJB
GFFETMPU

Intermec PC43d Specifications

General

Print Technology	Direct Thermal
Print Resolution	203 dpi (8 dots/mm)
Max Print Width	4.1 inches
Max Print Speed	8 ips
Connectivity	USB, Serial, Ethernet
Media Handling	fanfold
Memory	128 MB Flash, 64 MB SDRAM
Media Type	Tags
Roll Maximum Outer Diameter	5 inches
Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Storage Temperature	-20°C to +60°C (-4°F to +140°F)
Humidity	10 to 90% RH non-condensing
Power Requirements	100-240V AC, 50-60 Hz
