Inventec N800G3 - PCI-E Slot (J22, J81)

Connectors and Jumpers
2015-MNU-000009
3-12
3.12 PCI-E Slot (J22, J81)
Figure 3-12 PCI-E x16 Slots
Table 3-16 Pin Definition of PCI-E x16 Slots (J22, J81)
Signal Name
Pin
Pin
Signal Name
P12V
B1
A1
Ground
P12V
B2
A2
P12V
P12V
B3
A3
P12V
Ground
B4
A4
Ground
I2C_S9_CPU1_PE_R_SCL
B5
A5
JTAG_PE_SLOT6_TCK
I2C_S9_CPU1_PE_R_SDA
B6
A6
JTAG_PE_SLOT6_TDI
Ground
B7
A7
DC_J22_SLOT6_PIN_A7
P3V3
B8
A8
JTAG_PE_SLOT6_TMS
JTAG_PE_SLOT6_TRST
B9
A9
P3V3
P3V3_STBY
B10
A10
P3V3
PCIE_WAKE_N
B11
A11
RST_PERST_SLOT_R4_N
P3V3_R_SLOT6
B12
A12
Ground
Ground
B13
A13
CLK_100M_1_PE_SLOT6_DP
PE_CPU1_3A_TX_0_DP
B14
A14
CLK_100M_1_PE_SLOT6_DN
PE_CPU1_3A_TX_0_DN
B15
A15
Ground
Ground
B16
A16
PE_CPU1_3A_RX_0_DP
Ground
B17
A17
PE_CPU1_3A_RX_0_DN
Ground
B18
A18
Ground
PE_CPU1_3A_TX_1_DP
B19
A19
Ground
PE_CPU1_3A_TX_1_DN
B20
A20
Ground
Ground
B21
A21
PE_CPU1_3A_RX_1_DP
Ground
B22
A22
PE_CPU1_3A_RX_1_DN
