Inventec N800G3 - To Install the 10 G NIC Card; To Remove the 10 G NIC Card

Hardware Operations
2015-MNU-000023
2-13
Reminder
Before you remove or install the NIC card, please follow the steps below:
Step 1:
Make sure the server is not turned on or connected to the AC power. To power off
the server, see “2.1.1 Power Off”.
Step 2:
Remove the chassis cover. To remove the chassis cover, see “2.2 Chassis
Cover”.
Step 3:
Remove the PCI-E expansion card. To remove the PCI-E expansion card, see
“2.7 PCI-E Expansion Card”.
Step 4:
Disconnect all the necessary cables.
2.8.1 To remove the 10G NIC card
Loosen the retaining clips that secure the 10G NIC card.
Remove the 10G NIC card out of the motherboard as indicated.
Figure 2-22 Removing the10G NIC card
2.8.2 To install the 10G NIC card
Install the riser card in the slot on the motherboard.
Figure 2-23 Installing the Riser Card
